Vader Profile 700Ⅱ
Favolite's Vader Profile 700 Ⅱ:
The High-Brightness LED Fixture Revolutionizing Professional Lighting
Favolite Vader Profile 700Ⅱ, a cutting-edge 580W LED lighting fixture that sets new standards in high-brightness performance. This powerhouse of innovation is designed for the professional lighting designer who demands precision and versatility, making it the ultimate tool for Concert Touring, Stadium Sports Venues, Event Shows, and Cruise ships, as well as theaters and television studios. The Vader Profile 700Ⅱ is not just a lighting fixture; it’s a statement of intent, a beacon of brilliance that redefines what’s possible in professional lighting.
Unveiling a new era of illumination, the Vader Profile 700Ⅱ boasts a staggering brightness of 60,520Lux at 5 meters with a 6.5° beam angle. This luminous intensity ensures that even the largest of venues are bathed in a flood of light, making it the perfect choice for those seeking to make a grand visual impact. Its high brightness is not just a feature; it’s a promise of clarity and brilliance in every performance.
The Vader Profile 700Ⅱ is a master of adaptability, offering a multi-function arsenal that includes Beam, Wash, Spot, and Profile modes, along with CMY, Animation wheel, and more. This versatility means that whether you’re illuminating a stage, highlighting a sports event, or creating a mesmerizing light show, the Vader Profile 700Ⅱ has the power to deliver. Its smooth, fast, and accurate framing system can rotate a full 180°, providing the precision control that professionals require to frame their vision perfectly.
Color is crucial in lighting, and the Vader Profile 700Ⅱ delivers with Linear CMY+CTO and uniform color mixing. This advanced color technology ensures that every shade is reproduced with accuracy and vibrancy, allowing designers to paint with light in a way that was previously unimaginable. The result is a lighting experience that is as rich and diverse as the performances it enhances.
In environments where silence is golden, the Vader Profile 700Ⅱ stands out as a beacon of quiet excellence. Its whisper-quiet operation makes it ideal for noise-sensitive applications like theater, where the slightest whisper can steal the spotlight. At just 25kg, the Vader Profile 700Ⅱ is also lighter than similar products by 24%-35%, making it easier to transport and install without sacrificing any performance.
For concert touring, the Vader Profile 700Ⅱ is the lighting partner that can handle the rigors of the road, delivering powerful performance night after night. In stadium sports venues, it ensures that every play is visible, every moment is captured, and every fan is part of the action. Event shows come alive with the Vader Profile 700Ⅱ’s ability to create dynamic light displays that captivate audiences. And on cruise ships, it provides the atmospheric lighting that enhances the sense of luxury and excitement.
The Favolite Vader Profile 700Ⅱ is more than just a lighting fixture; it’s a key component in creating unforgettable experiences. It’s the difference between good lighting and great lighting, between a performance and a spectacle. With the Vader Profile 700Ⅱ, precision and power meet in perfect harmony, offering a lighting solution that’s as adaptable as it is impressive. Experience the future of professional lighting with the Favolite Vader Profile 700Ⅱ – where every event is a masterpiece illuminated.
Quick Features
- High brightness: 72,636Lux@5m, 6.5°
- Multi-function: Beam, Wash, Spot, Profile, CMY, Animation wheel etc
- Linear CMY+CTO, uniform color mixing
- Smooth, fast and accurate framing, can rotating 180°
- Lighter than similar products,24%-35%, only 25kg
- Really quiet, suitable for the noise-sensitive application, like theater
Superior
Specification
OPTICS
- Light Source :580W White LED Module
- Lifetime: 50000 Hours
- Lumen: 20500lm
- Color temperature:
-CRI: at least 70, CT 6500K
-CRI: at least 90, CT 7000K
MOVEMENT
- Pan movement:540° (16 bit)
- Tilt movement :270° (16 bit)
- Automatic reset function
COLORS
- Colors wheel:1+6colors, Bi-directional rainbow effect
- Linear CMY+CTO
GOBOS
- Fixed gobo wheel:
8 gobos + open - Rotating gobo wheel:
6 HD interchangeable gobos +open - Rotating Gobo size:Outside-27.9MM
Inside-22MM;Thickness-1.1 MM
- Bidirectional variable rotation, Index functions Bi-directional changeable speed shake effect
changeable speed and flow effect - Animation Wheel:Unlimited rotation
flow and flame effect
FEATURE
Prism: 1 rotating prisms
4-facet circular prism
(3,8,16,24 facet option)- Iris: Linear adjustable with macro
- Frost: Soft edge frost and flood frost
- Focus: DMX 512 linear focus
- Zoom:6.5-42linear adjustment, smooth and fast
- Dimmer: 0-100% linear dimmer
- Strobe: Electronic strobe,0.3-20Times/SEC
FRAMING SYSTEM
- Motorized framing system with 4 focal planes
- 4 Blades that move separately
- Smooth, flexible blade movements at variable speed
- Framing system smooth movement and extremely accurate position
- Single blade full blackout
- Framing system indexable over 180°
CONTROLAND PROGRAMMING
- Standard mode: 39/41 channels
- Fan mode: NORMAL/PERFORMANCE/QUIET
- Control mode: DMX512, Protocols RDM, Wireless , Art-Net and sACN
- DMX,sACN and RDM data in/out
OTHER FUNCTION
- 2.4inch color LCD screen
- High reliability touch button
- Support auto flip display
- Support Multi-language
- Automatic monitoring of light source temperature, high temperature automatic protection
- Intelligent cooling system
- DMX512 Software update
- Display light use time
- Low level linearity, flicker free film TV
- Maintenance mode
Menu setting by internal rechargeable battery
without power supply
(3.7V rechargeable lithium-ion battery)- Intelligent control of wind speed
- Reverse display
- Control panel lock
Manual programming
POWER SUPPLYAND CONNECTIONS
- Input voltage:100V~240V AC 50/60Hz
- Rate power:800W@220V
- Power socket: power connector input
- DMX and RDM data in/out: Locking 3-pin/5-pin XLR, RJ45 in
HOUSING
- Environmentally friendly flame retardant materials
- High temperature resistant engineering plastics
- Device locking PAN and TILT mechanisms for transportation and maintenance
- Intellectual property rights of appearance and structure design
IP GRADE
IP:20
DIMENSION
Product Size: 395 x 338 x 638 MM
-15.55″x 13.31″x 25.12″
Carton size(1in1):750 x 460 x 520 MM
-29.53″x 18.11″x 20.47″
Flight case size(1in1): 550 x 470 x 875 MM
-21.65″x 18.50″x 34.45″
Flight case size(2in1):940 x 470 x 870 MM
-37.01″x 18.50″x 34.25″
WEIGHT
- Net weight:25KG
SIZE
Quicky
Quick Channel
1 Pan
2 Pan fine
3 Tilt
4 Tilt fine
5 Colour wheel
6 Cyan
7 Magenta
8 Yellow
9 Colour temperature
10 Fixed gobo
11 Rotating gobo
12 Gobo rotation
13 Dimmer
14 Dimmer fine
15 Strobe
16 Dimmer mode
17 Prism 1
18 Prism 1 rotation
19 Zoom
20 Zoom fine
21 Focus
22 Focus fine
23 Auto focus distance
24 Auto focus distance fine
25 Iris open
26 Frost
27 Animation Wheel
28 Animation Movement
29 Frame 1A
30 Frame 1B
31 Frame 2A
32 Frame 2B
33 Frame 3A
34 Frame 3B
35 Frame 4A
36 Frame 4B
37 Frame Angle
38 Frame Angle Fine
39 Frame Macro
40 Scan Speed
41 Control
22 Focus fine
23 Auto focus distance
24 Auto focus distance fine
25 Iris open
26 Frost
27 Animation Wheel
28 Animation Movement
29 Frame 1A
30 Frame 1B
31 Frame 2A
32 Frame 2B
33 Frame 3A
34 Frame 3B
35 Frame 4A
36 Frame 4B
37 Frame Angle
38 Frame Angle Fine
39 Frame Macro
40 Scan Speed
41 Control
EFFECT
Gobos & Animation wheel
Rotating Gobo
Fixed Gobo
Animation Wheel
your pain
Do you have such troubles?
Slient
like theater
Your customer:
Too noisy!
Lighter
Your colleague:
Too heavy!
Linear CMY
Your Lighting Designer:
Oh ,Color!
Flicker-free Function
HD or UHD camera
Your Photographer: Flicker!
Feature
High Brightness
- 72,636Lux@5m, 6.5°
- 20500lm
Uniform Color Mixing:
-
Cutting CMY
compared to Rotating CMY is super uniform Import glass material -
High temperature resistant
non-explosive Reasonable structural design
Precise Framing Control
-
Precise Framing Control
Smooth, fast, and accurate framing -
4 focal blades and 10 driving motors
-
rotated over 180°
FILES
Download
Package
Flight Case or Carton ?
**For reference only, the actual product shall prevail.
Auxiliary
Accessories
**For reference only, the actual product shall prevail.
It has better performance,higher Cooling efficiency it Ensure the LED light source,
Has longer life Time
camera will focus on the lights.
Sometimes you will find it has flicker, like this
And our Vader 700 can avoid this situation,
only adjust the PWM control system.
You can see,use frequency control,
it can flicker free under HD and UHD camera operation.
So Vader 700 is very suitable for stage, theatre, TV show, etc.
More Vader Profile 700Ⅱ !
Framing system-Vader Profile 700Ⅱ:yes;Vader BWS 700Ⅱ:no;
Artnet,sACN, Wireless-Vader Profile 700Ⅱ:yes;Vader BWS 700Ⅱ:no.
As Rate power:800W@220V is large, to avoid safety risks.
If power out is needed, it can be added(a little money),
and we will use the laser to mark the total power on
the back panel, which needs your engineer
to calculate the number of units allowed to be connected.
There are 2 types of light sources available .
1.High brightness light source, CRI ≥ 70,
suitable for events, outdoor, concerts and other occasions.
2.High CRI light source, CRI ≥ 90,
brightness 70% of the previous type,
production time will be longer 30-50 days.
It is very suitable for high CRI requirements occasions,
such as theaters, television stations, and studios.
3.Besides brightness and CRI, production time,
4.Both light sources are from Osram, and the price is the same.
5.If not customized, We will delivery high brightness light sources.
Vader Profile 700 II has 3 pin AND 5 pin DMX,
You just need to tell us, 3 pin or 5 pin,
and we will configure the corresponding signal line for you.
